Description
Jiangsu Liangyi is professional manufacturer of 1.2888 ,X20CoCrWMo109,X20CoCrWMo10-9,X20CoCrWMo10.9 open die forging parts and seamless rolled steel forged rings from china
Following is the shape of 1.2888 ,X20CoCrWMo109,X20CoCrWMo10-9,X20CoCrWMo10.9 forging steel material that we could do is:1.2888 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,1.2888 Forged forging steel rings seamless rolled rings,X20CoCrWMo10-9 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,X20CoCrWMo10-9 Forged Forging Steel Discs Disks Blocks plates,1.2888 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
FOllowing is use of 1.2888 forged parts
Forged 1.2888 Extrusion Dies For Magnesium Copper Brass zinc Aluminum Extrusion Presses Extrusion
Forged 1.2888 Extrusion stems For Magnesium Copper Brass zinc Aluminum Extrusion Presses Extrusion
Forged 1.2888 Extrusion tools for copper, copper alloys and steel, brass extrusion
Forged 1.2888 Extrusion Bolster for copper, copper alloys and steel, brass extrusion
Forging 1.2888 extrusion die holder for copper, copper alloys and steel, brass extrusion presses
Forged X20CoCrWMo10-9 goosenecks and chambers for magnesium die casting
Forging 1.288 extrusion dummy blocks for copper, copper alloys and steel, brass extrusion presses
FOllowing is melting methods for all 1.2888 ,X20CoCrWMo10-9 forged material as per client choices
1 EAF: Electric Arc Furnace
2 EAF+LF+VD: Refined-smelting and vacuum degassing
3 EAF+ESR: Electro Slag Remelting
4 EAF+PESR: protective atmosphere Electro Slag Remelting
5 VIM+PESR: Vacuum induction melting
FOllowing is chemical compostion of 1.2888 ,X20CoCrWMo109,X20CoCrWMo10-9,X20CoCrWMo10.9 forged steel rings
C(％) 0.17-0.23
Si(％) 0.15-0.35
Mn(％) 0.40-0.60
P(％) Max 0.035
S(％) Max 0.035
Cr(％) 9.00-10.00
Mo(％) 1.80-2.20
Co(%) 9.50-10
Following is heat treatment way of 1.2888 forged parts
Soft Annealing
Heat to 760-840degree, cool slowly in furnace. Time is 4-6 hours. This will produce a maximum Brinell hardness of 320.
Stress Relieving
Stress relieving to remove machining stresses should be carried out by heating to 600-650degree,holding for 1-2 hours at heat, followed by air coling. This operation is performed to reducedistortion during heat treatment.
Hardening
Harden from a temperature of 1100-1150degree followed by air, oil quenching or vacuumquenching. Hardness after quenching is about 52 HRC.
Tempering
Tempering temperature: 600-750degree, to increase hardness, temper 2 or 3 times.
ALl our finished 1.2888 forging parts should be accepted by the QC department of the manufacturer by conducting the following
examinations:
1) external examination;
2) a check of dimensions and marking;
3) chemical composition examination;
4) mechanical tests;
5) macrostructure examination;
6) residual stress measurement;
7) ultrasonic testing;
8) periscopic testing.
Welcome your inquiry of 1.2888 ,X20CoCrWMo109,X20CoCrWMo10-9,X20CoCrWMo10.9 forging parts
