Description
Jiangsu Liangyi is professional manufacturer of ASTM A182 Grade F51,UNS S31803，A182-F51 ,F51 ,ASTM A 182 F 51 Duplex Stainless Steel open die forging parts and seamless rolled steel forged rings from china
Following is the shape of ASTM A182 Grade F51,UNS S31803，A182-F51 ,F51 ,ASTM A 182 F 51 forging steel material that we could do is:A182-F51 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,ASTM A 182 F 51 Forged forging steel rings seamless rolled rings,ASTM A182 Grade F51 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,ASTM A182 Grade F51 Forged Forging Steel Discs Disks Blocks plates,A182-F51 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
Following is forging products of ASTM A182 Grade F51,UNS S31803，A182-F51 ,F51 ,ASTM A 182 F 51 material that is used in following industry
ASTM A 182 F 51 forging Forged Drilling Pipes Tubes Drill Rods drill Drilling collar
ASTM A182 Grade F51 Forged Forging Turbine and Compressor Labyrinth Shaft Seals
ASTM A 182 F 51 Forged/Forging Blow Out Blowout Preventer RAM Annular dual Bop Body Bodies Block
ASTM A182 Grade F51 Forged Forging drilling tools,risers,connectors,flexible joint ,seals,flanges gasket
A182-F51 Forged Forging Valve Balls,valve Bonnets,valve Body Bodies ,valve Stems,valve closures, valve seat rings, valve core, valve discs,for H type two way 2‐way one way back pressure valves, ball valve,check valve,gate valve
ASTM A182 Grade F51 Forged Forging Steel nuclear Power
UNS S31803 Forged Forging Steel Butterfly Valve Main Shafts Spindles
ASTM A182 Grade F51 Forged Forging Swept branches outlets steel fittings swept saddles
A182-F51 Forged Forging downhole drilling tool Mud Motor Splined Drive shafts,Down hole Electric electrical submersible pumps ESP motor Splined Shaft
ASTM A 182 F 51 Forged Forging Steels Christmas Trees wellhead Spool Body Bodies cylinder
UNS S31803 Forged Forging venturi cone meter Body Bodies Blocks
ASTM A182 Grade F51 Forged Forging Steel gate valves Body Bodies bespoke flat bars
A182-F51 forged steel Flowseal cryogenic High Performance BV Butterfly Valves HPBV shaft
A182-F51 forging steel Oil measurement valve Spool Ultrasonic flow meter bodies Body
ASTM A 182 F 51 Forged Forging Steel double studded adapter flange
ASTM A 182 F 51 Forged Forging Steel integral Mud Flange Flanged outlet Studded crosses
ASTM A182 Grade F51 Forged Forging Steel Casing Heads,Tubing Heads,Casing Hangers,Tubing Hangers,Tubing Spools,Casing Spools,Spacer Spools
ASTM A 182 F 51 Forged Forgig Steel nuclear reactor coolant pump Casing Shells body bodis blocks,nuclear reactor coolant pumps containment seal chamber Rooms,nuclear reactor coolant pumps containment seal chamber Rooms
UNS S31803 Forged Forging turbomachinery turbo centrifugal compressor Impeller,Compressor Shrouded Impellers
ASTM A 182 F 51 Forged Forging Steel Forged Single Double Bossed boss Blanks FLANGED BOSSES
ASTM A 182 F 51 Forged Forging Steel PUMP Casing cover.PUMP BARREL,pump impeller,pump shafts, pump housing, pump shells,pump body,pump wear rings,pump case casing.
ASTM A182 Grade F51 Forged Forging forge Steel transition Cone
ASTM A182 Grade F51 Forged Forging Steel Pressure Vessel Reactor Nozzles
A182-F51 forged forging steel pipes tubes shells piping tubing barrels housing, tube sheets,baffle plates, nozzles, channel flanges for boiler, heat exchanger,pressure vessel,reactors, heaters
A182-F51 is duplex stainless steel with a 50:50 austenite, ferrite microstructure. The material combines good mechanical strength and ductility with moderate to good corrosion resistance in a variety of environments. This material is generally supplied in the annealed condition giving yield strengths in excess of 65 KSI 450Mpa), this material cannot be hardened by heat treatment but stronger surface strengths can be achieved by cold working. Typical applications include pumps, valves, pipework, flanges etc together with various applications in the oil and gas, brewing, power generation and chemical engineering industries.
FOllowing is chemical compostion of ASTM A 182 F 51,UNS S31803 forged steel rings
C 0.03 max
Mn 2.0 max
P 0.03 max
S 0.02 max
Si 1 max
Cr 21-23
Ni 4.5-6.5
Mo 2.5-3.5
N 0.80-0.20
Following of A182-F51,UNS S31803 forging parts heat treatment nechanical property Delivery condition :
Properties Metric Imperial
Tensile strength at break 621 MPa 90000 psi
Yield strength (@strain 0.200 %) 448 MPa 65000 psi
Elongation at break (in 50 mm) 25.0 % 25.0 %
Hardness, Brinell 293 293
Following is inspection standard of A182-F51,UNS S31803 forged parts
ASTM A604 Standard test methods for macroetch testing of consumable electrode
remelted steel bars and billets
ASTM E112 Standard test methods for determining average grain size
EN ISO 6892-1:20 Metallic materials -Tensile testing -Part 1:Method of test at ambient temperature
ISO 204:2009 Metallic materials -Uniaxial creep testing in tension -Method of test
EN 10204 Metallic products -Types of inspection documents
EN ISO/IEC 17050:2004 Conformity assessment -Supplier's declaration of conformity -General requirements
For Every pieces of A182-F51,UNS S31803 forging round bars, we could do following testing Non destructive tests such as visual, dimensional, ultrasonic testing,dye penetrant testing , Magnetic particle test(MPl), the mirrostructure and technological tests such as tensile, resilience, creep tests, hardness,Metallographic exams,Chemical analysis
MARKING of our finished forged A182-F51,UNS S31803 bars
Each part shall be stamped with:
The purchaser's part number
The purchaser's purchase number
The individual number
The heat number,if traceability to heat number is not possible by the individual number
The marking shall be surrounded by a frame or painted over with white durable paint.
Welcome your inquiry of ASTM A182 Grade F51,UNS S31803，A182-F51 ,F51 ,ASTM A 182 F 51 forging forged steel parts
