Description
Jiangsu Liangyi is professional manufacturer of 1.4466,X1CrNiMoN25-22-2,X1CrNiMoN25222,X1CrNiMoN25.22.2 open die forging parts and seamless rolled steel forged rings from china
Following is the shape of 1.4466,X1CrNiMoN25-22-2,X1CrNiMoN25222,X1CrNiMoN25.22.2 forging steel material that we could do is:X1CrNiMoN25-22-2 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,X1CrNiMoN25.22.2 Forged forging steel rings seamless rolled rings,1.4466 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,1.4466 Forged Forging Steel Discs Disks Blocks plates,X1CrNiMoN25-22-2 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
Following is forging products of 1.4466,X1CrNiMoN25-22-2,X1CrNiMoN25222,X1CrNiMoN25.22.2 material that is used in following industry
X1CrNiMoN25.22.2 forging Forged Drilling Pipes Tubes Drill Rods drill Drilling collar
1.4466 Forged Forging Turbine and Compressor Labyrinth Shaft Seals
X1CrNiMoN25.22.2 Forged/Forging Blow Out Blowout Preventer RAM Annular dual Bop Body Bodies Block
1.4466 Forged Forging drilling tools,risers,connectors,flexible joint ,seals,flanges gasket
X1CrNiMoN25-22-2 Forged Forging Valve Balls,valve Bonnets,valve Body Bodies ,valve Stems,valve closures, valve seat rings, valve core, valve discs,for H type two way 2‐way one way back pressure valves, ball valve,check valve,gate valve
X1CrNiMoN25.22.2 Forged Forging Steel Butterfly Valve Main Shafts Spindles
1.4466 Forged Forging Swept branches outlets steel fittings swept saddles
X1CrNiMoN25-22-2 Forged Forging downhole drilling tool Mud Motor Splined Drive shafts,Down hole Electric electrical submersible pumps ESP motor Splined Shaft
X1CrNiMoN25.22.2 Forged Forging Steels Christmas Trees wellhead Spool Body Bodies cylinder
1.4466 Forged Forging venturi cone meter Body Bodies Blocks
1.4466 Forged Forging Steel gate valves Body Bodies bespoke flat bars
X1CrNiMoN25-22-2 forged steel Flowseal cryogenic High Performance BV Butterfly Valves HPBV shaft
X1CrNiMoN25-22-2 forging steel Oil measurement valve Spool Ultrasonic flow meter bodies Body
X1CrNiMoN25.22.2 Forged Forging Steel double studded adapter flange
X1CrNiMoN25.22.2 Forged Forging Steel integral Mud Flange Flanged outlet Studded crosses
1.4466 Forged Forging Steel Casing Heads,Tubing Heads,Casing Hangers,Tubing Hangers,Tubing Spools,Casing Spools,Spacer Spools
X1CrNiMoN25.22.2 Forged Forgig Steel nuclear reactor coolant pump Casing Shells body bodis blocks,nuclear reactor coolant pumps containment seal chamber Rooms,nuclear reactor coolant pumps containment seal chamber Rooms
X1CrNiMoN25.22.2 Forged Forging turbomachinery turbo centrifugal compressor Impeller,Compressor Shrouded Impellers
X1CrNiMoN25.22.2 Forged Forging Steel Forged Single Double Bossed boss Blanks FLANGED BOSSES
X1CrNiMoN25.22.2 Forged Forging Steel PUMP Casing cover.PUMP BARREL,pump impeller,pump shafts, pump housing, pump shells,pump body,pump wear rings,pump case casing.
1.4466 Forged Forging forge Steel transition Cone
1.4466 Forged Forging Steel Pressure Vessel Reactor Nozzles
X1CrNiMoN25-22-2 forged forging steel pipes tubes shells piping tubing barrels housing, tube sheets,baffle plates, nozzles, channel flanges for boiler, heat exchanger,pressure vessel,reactors, heaters
1.4466 is fully austenitic stainless steel that does not have intermetallic phases such as intergranular carbide precipitations. 1.4466 steel grade has an optimized chemical composition designed specifically for applications in urea plants
FOllowing is production standard of 1.4466 forged material
EN 10088-3: 2005 Stainless steels. Technical delivery conditions for semi-finished products, bars, rods, wire, sections and bright products of corrosion resisting steels for general purposes
EN 10028-7: 2007 Flat products made of steels for pressure purposes. Stainless steels
EN 10088-1: 2005 Stainless steels. List of stainless steels
EN 10088-5: 2009 Stainless steels. Technical delivery conditions for bars, rods, wire, sections and bright products of corrosion resisting steels for construction purposes
- MACROSTRUCTURE LIMITS of 1.4466 forging materialis as follow
Class Condition Severity
1 Freckles A
2 White Spots A
3 Radial Segregation A
4 Ring Pattern B
FOllowing is chemical compostion of X1CrNiMoN25.22.2 forged steel rings
Iron, Fe Balance
Chromium, Cr 24-26
Nickel, Ni 21-23
Molybdenum, Mo 2-2.50
Manganese, Mn ≤ 2
Nitrogen, N 0.10-0.16
Silicon, Si ≤ 0.70
Phosphorous, P 0.025
Carbon, C ≤ 0.020
Sulfur, S ≤ 0.010
Following of X1CrNiMoN25-22-2 forging parts heat treatment nechanical property Delivery condition :
Rm - Tensile strength (MPa) (+A) 540-740
Rm - Tensile strength (MPa) (+AT) 540-740
Rp0.2 0.2% proof strength (MPa) (+A) 250
Rp0.2 0.2% proof strength (MPa) (+AT) 260
KV - Impact energy (J) transverse, (+A) +20°60 -196°60
KV - Impact energy (J) longitud., (+A) +20°100
A - Min. elongation at fracture (%) (+A) 35-40
A - Min. elongation at fracture (%) longitud., (+AT) 40
A - Min. elongation at fracture (%) transverse, (+AT) 30
Brinell hardness (HB): (+A) 240
All our X1CrNiMoN25-22-2 forging material will have following testing procedure
Visual inspections – Direct and Indirect
Magnetic particle
Dye penetrant – Visible and Fluorescent
Ultra-sonic testing
Radiograph
Metallurgical Testing
Macro & micro
Grain size determination
Charpy Impact testing
V notch Charpy
Hardness testing including micro and
macro Vickers tests
Tensile testing
Microscope imaging
Welcome your inquiry of 1.4466,X1CrNiMoN25-22-2,X1CrNiMoN25222,X1CrNiMoN25.22.2 forging forged steel parts
