Description
We are professional Forged Steel compressor impeller , Forging Steel shrouded centrifugal compressor impeller from china
Impeller is The key component that makes a compressor centrifugal is the centrifugal impeller, which contains a rotating set of vanes (or blades) that gradually raises the energy of the working gas. This is identical to an axial compressor with the exception that the gases can reach higher velocities and
energy levels through the impeller's increasing radius. In many modern high-efficiency centrifugal compressors the gas exiting the impeller is traveling near the speed of sound.
FOllowing is material grade that is normally used on forging compressor impeller
1.4418 X4CrNiMo16-5-1
1.4313, X3CrNiMo13-4, AISI 415,A182-F6NM
AISI 4140, AISI 4340
NiCr19NbMo,2.4668,UNS N07718,AMS 5662,Inconel 718
Haynes 230,UNS N06230, 2.4733, Alloy 230
Haynes 188 ,UNS R30188, 2.4683, Alloy 188
AMS 5706,AMS5707,Waspaloy, Uns N07001
Inconel 617,UNS N06617, 2.4663, Alloy 617
Nimonic 901,Nimonic Alloy 901, 2.4662, Alloy901
A182-F310,AISI 310, UNS S31000, 1.4810, A182 F310
Inconel 690,UNS N06690, 2.4642, Alloy 690
Inconel 783,Alloy 783, UNS R30783, Inconel783
Inconel X-750,UNS N07750, 2.4669, Alloy X-750
Nimonic 80A,UNS N07080, 2.4952, Alloy 80A
Nimonic 90,UNS N07090, 2.4632, Alloy 90
Nimonic 75,UNS N06075, Nimonic Alloy 75, 2.4951
Nimonic 263,UNS N07263, 2.4650, Alloy 263
AISI 416,A182 F22
Alloy 450,Alloy 455,AISI 422
X17CrNNi16-2,1.4057,AlS1431,UNSS43100,AMS 5628
X5CrNiCuNb16-4,1.4542,AlSI630,UNSS17400,AMS 5604 SUS630
X5CRNICU15-5,XM-12,1.4545,UNS S15500,AMS 5659
X4NICRTI25-15,A286,1.4944,1.4943.1.4980,AlSI660,UNS S66286,AMS 5525,AMS 5731,AMS 5732
We have following production equipment to produce all forging compressor impeller
Vacuum Induction Melting (VIM)
Argon Oxygen Decarburization (AOD)
Vacuum Arc Remelting (VAR)
Electro Slag Remelting (ESR)
Hydraulic Press
Radial Forging Machine
Machining
Weld Overlay
We could make forging , heat treatment and rough machined forging compressor impeller, our clients final machined in their place, also we could final machined compressor impeller as per clients drawing
We conduct a rigorous and wide range of test and inspection to ensure safe and superior quality products of all our forging compressor impeller
Chemical analysis by ASTM, ASME
Mechanical analysis
Tensile test by ASTM A370, E8/E8M
High temperature tensile test by ASTM E21
Impact test by ASTM A370, E23
Stress rupture test by ASTM E139
Micro structure test by ASTM E407
Macro structure test by ASTM E340, E381
Corrosion test by ASTM A262, A923, G48
NDE (UT, PT, MT) by ASTM A388, A745, MIL-STD-2154
3D Dimensional check
EN10204 3.2 Certification
Welcome your inquiry of forged steel compressor impeller
