Description
We are professional Forged Forging Steel Trunnion Valve Balls, Floating Valve Balls, Three Way Valve Balls, Pipe Welded Valve Balls, Stem Valve Balls, Hollow Valve Balls manucturer from china
Product Type of our forged vall ball: trunnion ball, floating ball, spigot mounted, stem ball, three way ball, segmented ball, V type ball,
Size Range:
Ball for floating ball valve: NPS 1- 10 Inches
Ball for trunnion ball valve: NPS 1- 60 Inches
Pressure Rating: ANSI 150~2500Lbs, JIS 5K~30K, PN16~420
Sphericity:
ØNPS 1- 12 Inches: Minimum 20 micron (ìm )
ØNPS 12- 60 Inches: Minimum 30 micron (ìm )
Pressure Rating:150lb,300lb,600lb,900lb,1500lb,2500lb
Materials: we can provide carbon steel, stainless steel, cryogenic steel, and special alloy.
Following is material grade that normally used in forged steel valve seat rings
ASTM A105, Sa350 LF2,Sa350 LF6, ASTM A694 F60,ASTM A694 F52,AISI 4130,AISI 4140,AISI 8620,AISI 8630,AISI 4130,AISI 4140,AISI 4330V, A182-F11,A182-F22,A182-F91,A182-F92,A182-F9,A182-F6A, AISI 410,A182-F6NM,A182 F304 (L), A182F316 (L),A182-F321,A182-F317, A182-F347, 904L,Alloy 20,AL6XN, Xm-19, Duplex A182-F51, A182 F55, A182-F53,A182 F51.A182-F60,A182-F44,17-4PH,Inconel 625, inconel 690, inconel 600, inconel 617, inconel 718,, Monel 400, Monel R-405,Monel K-500,Titanium Gr3, Gr4, Gr7,Incoloy 800,800H,800HT,incoloy 926, incoloy 825, ,Hastelloy C276 , Hastelloy B2,Hastelloy C22, Hastelloy C4, Hastelloy B3,09G2S 09Г2С GOST etc
FOllowing is melting methods of Forging steel valve balls
1 EAF: Electric Arc Furnace
2 EAF+LF+VD: Refined-smelting and vacuum degassing
3 EAF+ESR: Electro Slag Remelting
4 EAF+PESR: protective atmosphere Electro Slag Remelting
5 VIM+PESR: Vacuum induction melting
We could forged, heat treatment and final machined valve balls as per clients drawing
We could do following surface finish of forged valve balls
Surface Hardening Materials Tungsten Carbide TCC, Chromium Carbide CCC, Stellite STL,
Nickel Bace Alloy Ni60 / Ni55, Plasma Nitriding, Hard Chromium HCR,
Nickel Phosphorus ENP
We are able to provide any kind of NDE ( Non-Destructive Examination) tests for our all finished forged steel valve balls.
PT (Penetrant test)
UT (Ultrasonic test)
PMI (Positive material Identification)
MT (Magnetic test)
Thickness test (for cladding, plating or coating)
Alcohol Test (for MTM kits)
Corrosion Test
ALl our finished forged valve balls will have Inspection certificate 3.1 acc.EN 10204
The inspection Certificate shall include:
1. Chemical Composition.
2.Melting method
3. Tensile testing acc.DIN EN 10002-1 (Tensile strength Technical elastic limit =0,2%,Elongation,Throat
4. Beam Impact Test (average out.of 3 testings) acc.DIN EN 10045-1 by using ISO-V notch specimen
5. Hardness test according DIN EN 10003-1 (Brinell)o DIN EN 10109-1(Rockwell C)at three spots across the total length
6.Proof of the inner consistency (UItrasonic testing acc.EN10228-3 Class 3 C)
7. Information on heat treatments (tempering,stress relief annealing,normalizing)
8. Dimension inspection (Dimension record)
9.Proof of surface roughness Rz in the bearing zones
10.Proof that the entire finished product is free from cracks (Magnetic particle test acc.EN10228-1 class 4)
