Description
Jiangsu Liangyi is professional manufacturer of 1.4406,X2CrNiMoN17-11-2,X2CrNiMoN17112,X2CrNiMoN17.11.2 open die forging parts and seamless rolled steel forged rings from china
Following is the shape of 1.4406,X2CrNiMoN17-11-2,X2CrNiMoN17112,X2CrNiMoN17.11.2 forging steel material that we could do is:X2CrNiMoN17-11-2 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,X2CrNiMoN17.11.2 Forged forging steel rings seamless rolled rings,1.4406 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,1.4406 Forged Forging Steel Discs Disks Blocks plates,X2CrNiMoN17-11-2 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
Following is forging products of 1.4406,X2CrNiMoN17-11-2,X2CrNiMoN17112,X2CrNiMoN17.11.2 material that is used in following industry
X2CrNiMoN17-11-2 Forged Forging Valve Balls,valve Bonnets,valve Body Bodies ,valve Stems,valve closures, valve seat rings, valve core, valve discs,for H type two way 2‐way one way back pressure valves, ball valve,check valve,gate valve
X2CrNiMoN17.11.2 Forged Forging Steel Butterfly Valve Main Shafts Spindles
1.4406 Forged Forging Swept branches outlets steel fittings swept saddles
X2CrNiMoN17-11-2 Forged Forging downhole drilling tool Mud Motor Splined Drive shafts,Down hole Electric electrical submersible pumps ESP motor Splined Shaft
X2CrNiMoN17.11.2 Forged Forging Steels Christmas Trees wellhead Spool Body Bodies cylinder
1.4406 Forged Forging venturi cone meter Body Bodies Blocks
1.4406 Forged Forging Steel gate valves Body Bodies bespoke flat bars
X2CrNiMoN17-11-2 forged steel Flowseal cryogenic High Performance BV Butterfly Valves HPBV shaft
X2CrNiMoN17-11-2 forging steel Oil measurement valve Spool Ultrasonic flow meter bodies Body
X2CrNiMoN17.11.2 Forged Forging Steel double studded adapter flange
X2CrNiMoN17.11.2 Forged Forging Steel integral Mud Flange Flanged outlet Studded crosses
1.4406 Forged Forging Steel Casing Heads,Tubing Heads,Casing Hangers,Tubing Hangers,Tubing Spools,Casing Spools,Spacer Spools
X2CrNiMoN17.11.2 Forged Forgig Steel nuclear reactor coolant pump Casing Shells body bodis blocks,nuclear reactor coolant pumps containment seal chamber Rooms,nuclear reactor coolant pumps containment seal chamber Rooms
X2CrNiMoN17.11.2 Forged Forging turbomachinery turbo centrifugal compressor Impeller,Compressor Shrouded Impellers
X2CrNiMoN17.11.2 Forged Forging Steel Forged Single Double Bossed boss Blanks FLANGED BOSSES
X2CrNiMoN17.11.2 Forged Forging Steel PUMP Casing cover.PUMP BARREL,pump impeller,pump shafts, pump housing, pump shells,pump body,pump wear rings,pump case casing.
1.4406 Forged Forging forge Steel transition Cone
1.4406 Forged Forging Steel Pressure Vessel Reactor Nozzles
X2CrNiMoN17-11-2 forged forging steel pipes tubes shells piping tubing barrels housing, tube sheets,baffle plates, nozzles, channel flanges for boiler, heat exchanger,pressure vessel,reactors, heaters
1.4406 is is a stainless austenitic chromium-nickel-molybdenum steel with nitrogen addition. It is used in the pharmaceutical industry, in the chemical industry and in the petrochemical industry.
1.4406 is widely used in Aerospace Structures.Base plates.Food processing equipment.Brewery equipment.Pulp and paper processing equipment.Oil & petroleum refining equipment.Chemical transportation containers.Soap and photographic handling equipment.Textile Industry Equipment.Architectural.Pharmaceutical processing equipment,Laboratory benches & equipment,Boat fittings,Heat exchangers
Following is production standard of 1.4406 forged material
EN 10088-3: 2005 Stainless steels. Technical delivery conditions for semi-finished products, bars, rods, wire, sections and bright products of corrosion resisting steels for general purposes
EN 10028-7: 2007 Flat products made of steels for pressure purposes. Stainless steels
EN 10222-5: 2000 Steel forgings for pressure purposes. Martensitic, austenitic and austenitic-ferritic stainless steels
EN 10272: 2007 Stainless steel bars for pressure purposes
EN 10250-4: 2000 Open steel die forgings for general engineering purposes. Stainless steels
EN 10088-1: 2005 Stainless steels. List of stainless steels
EN 10088-5: 2009 Stainless steels. Technical delivery conditions for bars, rods, wire, sections and bright products of corrosion resisting steels for construction purposes
Our X2CrNiMoN17.11.2 forged steel raw material is normal melting by Basic Electric Furnace (EAF, AOD, VOD) or + Electroslag remelting. (ESR) AS PER CLIENTS NEEDS
FOllowing is chemical compostion of X2CrNiMoN17.11.2 forged steel rings
Iron (Fe) 63.2 to 71.4
Chromium (Cr) 16.5 to 18.5
Nickel (Ni) 10 to 12.5
Molybdenum (Mo) 2.0 to 2.5
Manganese (Mn) 0 to 2.0
Silicon (Si) 0 to 1.0
Nitrogen (N) 0.12 to 0.22
Phosphorus (P) 0 to 0.045
Carbon (C) 0 to 0.030
Sulfur (S) 0 to 0.015
Following of X2CrNiMoN17-11-2 forging parts heat treatment mechanical property Delivery condition :
Rm - Tensile strength (MPa) (+A) 580-800
Rp0.2 0.2% proof strength (MPa) (+A) 280-315
A - Min. elongation at fracture (%) (+A) 30-40
A - Min. elongation at fracture (%) longitud., (+AT) 45
Brinell hardness (HB): (+A) 250
Following is inspection standard of 1.4406,X2CrNiMoN17-11-2 forged parts
ASTM A604 Standard test methods for macroetch testing of consumable electrode
remelted steel bars and billets
ASTM E112 Standard test methods for determining average grain size
EN ISO 6892-1:20 Metallic materials -Tensile testing -Part 1:Method of test at ambient temperature
ISO 204:2009 Metallic materials -Uniaxial creep testing in tension -Method of test
EN 10204 Metallic products -Types of inspection documents
EN ISO/IEC 17050:2004 Conformity assessment -Supplier's declaration of conformity -General requirements
All our finished 1.4406,X2CrNiMoN17-11-2 forged shafts should have following inspection report
Chemical compositions(on the sampling area on part and on thesample ingot)
Mechanical properties(on the sampling area on part and on the sample ingot)Hardness curve to characterize the surface hardened area
Roughness measurement
Metallurgical analysis: structure, grain size, inclusion cleanliness
Records of the heat treatment
Non-destructive test reports
Welcome your inquiry of 1.4406,X2CrNiMoN17-11-2,X2CrNiMoN17112,X2CrNiMoN17.11.2 forging forged steel parts
