Description
Jiangsu Liangyi is professional manufacturer of AISI 5120,SAE 5120,SAE5120,UNS G51200 open die forging parts and seamless rolled steel forged rings from china
Following is the shape of AISI 5120,SAE 5120,SAE5120,UNS G51200 forging steel material that we could do is:AISI 5120 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,AISI 5120 Forged forging steel rings seamless rolled rings,SAE 5120 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,AISI 5120 forging forged steel shafts,gear,pinion shafts,spindles,gear wheel,SAE 5120 Forged Forging Steel Discs Disks Blocks plates,AISI 5120 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
Following is forging products of AISI 5120,SAE 5120,SAE5120,UNS G51200 material that is used in following industry
AISI 5120 Forged Forging Sugar Mill Gear shafts,pinion shafts,roller shafts,flanges coupling
AISI 5120 Cement Mill Rotary Kiln Forged Forging Steel case hardened ground Pinion Shafts
SAE 5120 Forging Forging Steel mill gear pinion shafts
AISI 5120 Forging wind turbine gearbox gear shafts,ring gears
SAE 5120 forging forged locomotive transmission shafts
AISI 5120 forging forged crane wheels
AISI 5120 hydro turbine shafts
AISI 5120 Forging gearbox,gear reducer gear wheels, pinion shafts,ring gears,
AISI 5120 Forging crankshafts for gas compressor, mechanical presses,pump.
AISI 5120 forging steel Spindles
AISI 5120 Forging steel gear couplings
AISI 5120 Forged Forging Rolled Steel Granulators driers coaters coolers Riding Gear Rings
AISI 5120 Forged Forging Steel Cement Plant Pull Torque Rods
AISI 5120 Forged Forging Steel Crusher Shaft eccentric shafts,Mining Mine rock Gyratory crusher Eccentric shafts Spindles,Crusher Belt Pulley Wheels.
AISI 5120 Forged Forging Steel Mining Excavator Slewing Bearing Ball Races rings
AISI 5120 Forged Forging Steel Oil Drilling Tools Gear Shaft Pinion Shafts
AISI 5120 Forged Forging Steel helical gearing ground ship gearwheel Gear Wheels
UNS G51200 Forged Forging Steel Dragline Drag Line Power Shovel Cam Swing Shafts Shafting Spindles,dragline CENTRE PINTLE
AISI 5120 Forged Forging Steel Atomizer Shafts For Flue Gas Desulfurization scrubber Systems
UNS G51200 Forged Forging Steel drilling rigs Mud pump herringbone gear shafts pinion shafts
AISI 5120 Forging Forged Steel Thread Tie Rods
AISI 5120 Forged Forging Steel Electric Shovel Shaft Couplings
AISI 5120 Forged Forging Steel Granulator Gear Shafts
AISI 5120 Conveyor Pulley Forging Forged Steel Shafts factory
AISI 5120 Forged Forging Steel Hydraulic Honed Cylinders
AISI 5120 Forged Forging Steel Mine hoist systems Equipment Shaft Shafting Spindles
UNS G51200 Forged Forging Steel Rotary Dryer Trunnion Wheels
AISI 5120 Forged Forging Forge Steel Cold Mill Decoiler Coiler Mandrel Drum Shafts
AISI 5120 Forged Forging Steel bullgear Spider Gear Rims
AISI 5120 Forged Forging Shovel SWING Rimmed GEARING Gear DRUM GEAR,SWING PROPEL Pinion SHAFTS
UNS G51200 Forged Forging Steel Truck RING GEARS PLANET GEARS PINION SHAFTS
AISI 5120 Forging Forge Steel Offshore subsea anchor winches Stub Shafts Spindles
AISI 5120 Forged Forging Steel Seamless Hot rolled Truck concrete mixers semi-trailer bearings Rings
AISI 5120 Forged Forging Steel Subsea oil gas drilling equipments Box Riser Joint
AISI 5120 Forged Forging Railway locomotive Traction Motors end housings Rear End Shields
AISI 5120 Forged Forging Steels Christmas Trees wellhead Spool Body Bodies
AISI 5120 Forged Forging forge Steel Gas Steam turbine Power generator Shafts
AISI 5120 Forged Forging Steel Rotary Rock Drilling Tri-Cone Tricone Drill Bit cutter (PDC) Body Bodies factory
Forged Forging Steel Rotary Rock Drilling Tri-Cone Tricone Drill Bit cutter (PDC) Body Bodies
Steel making Process of AISI 5120,SAE 5120,SAE5120,UNS G51200 forging round bars
Electric arc furnace or blast furnace and oxygen blast converter shall be used, each with subsequent ladle treatment;
Steel shall be vacuum degassed;
Steel shall be non-radioactive;
Quality class shall beat least MQ in accordance with ISO 6336-5 or DIN 3990-5;
Standard EN 10083 shall be followed.
Chemical composition of AISI 5120,SAE 5120,SAE5120,UNS G51200 forged parts
Iron (Fe) 97.6 to 98.3
Manganese (Mn) 0.7 to 0.9
Chromium (Cr) 0.7 to 0.9
Silicon (Si) 0.15 to 0.35
Carbon (C) 0.17 to 0.22
Sulfur (S) 0 to 0.040
Phosphorus (P) 0 to 0.035
FOllowing is heat treatment way of AISI 5120 forged Raw Material
Soft Annealing
Heat to 650-700c, cool slowly. This will produce a maximum Brinell hardness of 207.
Carburizing
880-980 0c, water, oil, air, hot quenching 150-250Pc or case hardening box.
Core hardening
Temperature: 860-900c.
Surface hardening
Tempertaure: 720-820c.
Tempering
Tempering temperature: 150-200c.
we have following heat treatment and forging equipment to produce our AISI 5120,SAE 5120 forged parts
Forging Process:3200/4200/6000 t Open die presses
Manipulators, Lifting Capacity up to 60 t
Heating Forging Furnaces, Max Capacity 150 t
Furnaces for Hydrogen Bake-Out Up to 14 m
Heat Treatment Semi-automatic Heat Treatment System Quality Heat Treatment
Furnaces Max lenght 18 m Quenching tanks up to 16 m
Ultrasonic testing of AISI 5120,SAE 5120 forged bars
On each bar or cut section, ultrasonic testing is performed according to standard
EN 10308 for bars to a diameter up to 300 mm
EN10228-3 for bars with a diameter over 300 mm
Welcome your inquiry of AISI 5120,SAE 5120,SAE5120,UNS G51200 forging parts
