Description
Jiangsu Liangyi is professional manufacturer of ASTM A182 Grade F60,A182-F60 ,F60 ,ASTM A 182 F 60 open die forging parts and seamless rolled steel forged rings from china
Following is the shape of ASTM A182 Grade F60,A182-F60 ,F60 ,ASTM A 182 F 60 forging steel material that we could do is:A182-F60 Forged Steel round bars square bars Flat bars Rectangles Bars Rods,ASTM A 182 F 60 Forged forging steel rings seamless rolled rings,ASTM A182 Grade F60 Forged Forging Steel Hubs housing shell Sleeves Bushes Bushing Cases Hollow Bars,ASTM A182 Grade F60 Forged Forging Steel Discs Disks Blocks plates,A182-F60 Forged Forging Steel Pipe Tubes Tubings Piping Shells Casings Case barrels Housings.
Following is forging products of ASTM A182 Grade F60,A182-F60 ,F60 ,ASTM A 182 F 60 material that is used in following industry
ASTM A 182 F 60 forging Forged Drilling Pipes Tubes Drill Rods drill Drilling collar
ASTM A182 Grade F60 Forged Forging Turbine and Compressor Labyrinth Shaft Seals
ASTM A 182 F 60 Forged/Forging Blow Out Blowout Preventer RAM Annular dual Bop Body Bodies Block
ASTM A182 Grade F60 Forged Forging drilling tools,risers,connectors,flexible joint ,seals,flanges gasket
A182-F60 Forged Forging Valve Balls,valve Bonnets,valve Body Bodies ,valve Stems,valve closures, valve seat rings, valve core, valve discs,for H type two way 2‐way one way back pressure valves, ball valve,check valve,gate valve
ASTM A182 Grade F60 Forged Forging Steel nuclear Power
ASTM A 182 F 60 Forged Forging Steel Butterfly Valve Main Shafts Spindles
ASTM A182 Grade F60 Forged Forging Swept branches outlets steel fittings swept saddles
A182-F60 Forged Forging downhole drilling tool Mud Motor Splined Drive shafts,Down hole Electric electrical submersible pumps ESP motor Splined Shaft
ASTM A 182 F 60 Forged Forging Steels Christmas Trees wellhead Spool Body Bodies cylinder
ASTM A182 Grade F60 Forged Forging venturi cone meter Body Bodies Blocks
ASTM A182 Grade F60 Forged Forging Steel gate valves Body Bodies bespoke flat bars
A182-F60 forged steel Flowseal cryogenic High Performance BV Butterfly Valves HPBV shaft
A182-F60 forging steel Oil measurement valve Spool Ultrasonic flow meter bodies Body
ASTM A 182 F 60 Forged Forging Steel double studded adapter flange
ASTM A 182 F 60 Forged Forging Steel integral Mud Flange Flanged outlet Studded crosses
ASTM A182 Grade F60 Forged Forging Steel Casing Heads,Tubing Heads,Casing Hangers,Tubing Hangers,Tubing Spools,Casing Spools,Spacer Spools
ASTM A 182 F 60 Forged Forgig Steel nuclear reactor coolant pump Casing Shells body bodis blocks,nuclear reactor coolant pumps containment seal chamber Rooms,nuclear reactor coolant pumps containment seal chamber Rooms
ASTM A 182 F 60 Forged Forging turbomachinery turbo centrifugal compressor Impeller,Compressor Shrouded Impellers
ASTM A 182 F 60 Forged Forging Steel Forged Single Double Bossed boss Blanks FLANGED BOSSES
ASTM A 182 F 60 Forged Forging Steel PUMP Casing cover.PUMP BARREL,pump impeller,pump shafts, pump housing, pump shells,pump body,pump wear rings,pump case casing.
ASTM A182 Grade F60 Forged Forging forge Steel transition Cone
ASTM A182 Grade F60 Forged Forging Steel Pressure Vessel Reactor Nozzles
A182-F60 forged forging steel pipes tubes shells piping tubing barrels housing, tube sheets,baffle plates, nozzles, channel flanges for boiler, heat exchanger,pressure vessel,reactors, heaters
A182-F60 is Duplex Stainless Steel combines improved resistance to stress corrosion cracking, pitting, crevice corrosion and high strength
A182-F60 chemical compostion Shall conform to the percentages by weight shown in following table , determined by wet chemical methods in accordance with ASTM E 353, by spectrochemical methods, or by other analytical methods acceptable to purchaser.
FOllowing is chemical compostion of ASTM A 182 F 60 forged steel rings
Carbon0.030 max
Manganese2.00 max
Phosphorus0.030 max
Sulfur0.020 max
Silicon1.00 max
Nickel4.5- 6.5
Chromium22.00 - 23.00
Molybdenum3.00 - 3.5
Nitrogen 0.14- 0.20
Following of A182-F60 forging parts heat treatment nechanical property Delivery condition :
Tensile Strength, min, ksi [MPa]95 [655]
Yield Strength, min, ksi [MPa]65 [450]
Elongation in 2 in. [50mm] or 4D, min, %25
Reduction or Area, min, %45
The following test methods of A182-F60 forged rings shall be used during delivery inspection.
Tensile testing:EN ISO 6892-1.
Creep rupture testing:ISO 204.
UItrasonic testing shall be carried out in accordance with agreed testing procedure specification.
Macroetching:ASTM A604.
Grain size estimation:ASTM E112
Our A182-F60 forged material is qualified in certificate of ISO 9001,ISO 14001.ISO 50001,ISO 3834-2, ISO 9712,ISO/IEC 17025,NORSOK M122,NORSOK M123
All our A182-F60 forged steel parts can be release in 10204-3.2 certificate by following third party DNV-GL BUREAU VERITAS,LLOYD’S REGISTER,ABS, RINA,TÜV
Welcome your inquiry of ASTM A182 Grade F60,A182-F60 ,F60 ,ASTM A 182 F 60 forging forged steel parts
